Garmin GRS 77 Connector Kit
With Shield Block
Contains
Sub-Assy, Bkshl w/Hdw,25/44 Pin (Qty 1) – 011-00950-02
Sub-Assy, Configuration Module (Qty 1) – 011-00979-00
Sub-Assy, Grnd Harness,14 Ckt (Qty 1) – 011-00980-01
Lbl, Connector Kit,GRS77 (Qty 1) – 161-20444-00
Pkg,Polybag,Zip,5x8x2mil (Qt7 1) – 172-00021-15
Pkg,Polybag,Zip,10x12x4mil (Qty 1) – 172-00021-58
Screw,4-40x.375,PHP,SS/P,w/NYL (Qty 2) – 211-60234-10
Tbg, Ht Shrink,Tfl,FEP,.093 ID (Qty 6) – 312-00005-05
Conn, Plug, HD Dsub,44 CKT (Qty 1) – 330-00366-44
Dsub Slide Lock Kit,25/44 Pin (Qty 1) – 330-90006-02
Cont, Pin, Mil Crimp, Size 22D (Qty 30) – 336-00021-00
Contact, Crimp, size 22D,18AWG (Qty 4) – 336-00044-00
Required, Not furnished with kit
Product Structure,GRS77 (Qty Ref) – 009-00178-00
Bag, Roll, 3″x4″ (Qty AR) – 172-00025-00
NOTES
FOR S/N 525-0001 THROUGH 525-0359. GB
