Rogers RO4350B materials are proprietary woven glass reinforced hydrocarbon/ceramics with electrical performance close to PTFE/woven glass and the manufacturability of epoxy/ glass.

RO4350B laminates provide tight control on dielectric constant (Dk) and maintain low loss while utilizing the same processing method as standard epoxy/glass. Available at a fraction of the cost of conventional microwave laminates, RO4350B laminates do not require the special through-hole treatments or handling procedures as PTFE based materials. These materials are UL 94 V-0 rated for active devices and high power RF designs.

Features

• Dk of 3.48 +/- 0.05
• Dissipation factor of 0.0037 at 10 GHz
• Low Z-axis coefficient of thermal expansion at 32 ppm/°C
• High glass transition temperature
  (280°C).

Benefits

• Processes like FR-4 at lower fabrication cost
• Competitively priced
• Excellent dimensional stability

Availability

• SHEET SIZE: 12”X18” (305 X 457mm)
• THICKNESS: 0.51MM / 0.02 INCHES
• Standard Copper Cladding: 1/2 oz (17μm) and 1 oz (35μm) electrodeposited copper
